Pressure Balanced Bottom Valve C804LPQ-100
Size: 4″
Pressure-Balanced Type
When the valve is closed, the fuel pressure cannot push open the valve.
Special Surface Treatment
The whole valve body is passed a special surface process to improve the anti-corrosion.
Hydrodynamic Body
Design and high lift poppet minimizes pressure drop to give maximum flow rate.
External Shear Groove
Meets the standard requirements to limit product spillage in the event of an accident.
Manual Opening Device
When need to emergency discharging, the pneumatic control is useless, it can be opened by manual way.
Easy-Installment
The size of the valve is more smart, is suitable for the smaller space’s demand.
Technical Data:
Nominal Pressure: 0.6Mpa
Material: Aluminum Alloy
Open method: Pneumatic
Temperature Range: -20℃~+70℃
